TRANSPORT PLATFORM

Transport platforms are designed for a wide range of industrial applications, with its robust structure and capability of operating in dusty and high-temperature environments. They are ideal for material transport, saving time and cost. With a versatile platform and hoist mode, the translate platform offers efficient lifting at speeds of 12 m/min in platform mode and 24 m/min in hoist mode and up to a maximum height of 100 m.

Transport Platform

Download brochure

1 / 1

Videos

8 Safety Measures

●    Progressive overspeed safety device
●    Landing gate and platform gate interlocking device
●    Overload protection
●    Travel limit protection
●    Motor overheating protection
●    Manual descent in event of power loss
●    2-m alarm with audible and visual signal
●    Safety buffer

Product Details

Drive Unit

Driven by the gear motor, the drive unit propels the work platform to move up and down along the mast. In the event of power loss, the manual descent mechanism allows the platform to lower down to safety.

Overload Detection Device

When exceeding the rated load, the device activates an audible and visual alarm and prevents the platform from moving.

Guiding System

The transport platform is connected to the mast by means of guide rollers, ensuring that the platform travels in the designed route.

Overspeed Safety Device

The device operates automatically when the platform travel speed exceeds the set limit, stopping the platform immediately and disconnecting the power.

Travel Limit Switch

By actuating the travel limit switch, the transport platform stops smoothly at the bottom or top of the mast.

Bottom Sensing Assembly

The transport platform stops automatically when it is obstructed by obstacles. When the switch is actuated, the platform can travel up but not down.



Retaining Rod

To prevent the tilting and falling of the platform.



Falling Object Protection Guarding Plate

To prevent injury from falling objects and to provide shade and protection from rain and snow.

Drive Unit

Driven by the gear motor, the drive unit propels the work platform to move up and down along the mast. In the event of power loss, the manual descent mechanism allows the platform to lower down to safety.

Overload Detection Device

When exceeding the rated load, the device activates an audible and visual alarm and prevents the platform from moving.

Guiding System

The transport platform is connected to the mast by means of guide rollers, ensuring that the platform travels in the designed route.

Overspeed Safety Device

The device operates automatically when the platform travel speed exceeds the set limit, stopping the platform immediately and disconnecting the power.

Travel Limit Switch

By actuating the travel limit switch, the transport platform stops smoothly at the bottom or top of the mast.

Bottom Sensing Assembly

The transport platform stops automatically when it is obstructed by obstacles. When the switch is actuated, the platform can travel up but not down.



Retaining Rod

To prevent the tilting and falling of the platform.



Falling Object Protection Guarding Plate

To prevent injury from falling objects and to provide shade and protection from rain and snow.

01 / 04

Key Features

  • Multiple safety features ensure peace of mind.
  • Automatic landing leveling function allows reaching the designated landing by one button.
  • Faults display on LCD screen, facilitating maintenance.
  • Mode switch between platform mode and hoist mode.
  • High strength, durable, and long service life.

SPECIFICATIONS

Transport Platform 3S 500H/HP

Model 3S 500H/HP
Rated load 500 kg
Maximum number of persons 3
Travel speed (hoist mode) 24 m/min
Travel speed (platform mode) 12 m/min
External platform dimensions 1700 mm × 1400 mm
Maximum height 100 m
Motor power 5.5 kW
Power supply 400 V 3P + N + PE 50 Hz

Transport Platform 3S 2000H/HP

Model 3S 2000H/HP
Rated load 2000 kg
Maximum number of persons 7
Travel speed (hoist mode) 24 m/min
Travel speed (platform mode) 12 m/min
External platform dimensions 4300 mm × 1700 mm
Maximum height 100 m
Motor power 2 × 7.5 kW
Power supply 400 V 3P + N + PE 50 Hz

Transport Platform 3S 1500H/HP

Model 3S 1500H/HP
Rated load 1500 kg
Maximum number of persons 7
Travel speed (hoist mode) 24 m/min
Travel speed (platform mode) 12 m/min
External platform dimensions 3200 mm × 1400 mm
Maximum height 100 m
Motor power 7.5 kW
Power supply 400 V 3P + N + PE 50 Hz
