XP Series Suspension Platform

With all aluminum column body, the Suspension Platform is used in multiple fields of operation platform. It is light in weight, compact, anti-resistant, safe, and convenient.

The XP Series Suspension Platform is composed of main components such as suspension device, platform, traction hoist, SafeLock, electric control system, wire rope, etc.; The suspension device is fixed on the roof, and the platform relies on its own hoist to climb along the steel wire rope, which can run vertically up and down, and freely hover at any height for work. The entire system is self-contained and does not require any external assistance, making it flexible and convenient. The modular main structure and standard sections made of aluminum alloy material are spliced into a platform of the required length.

XP Series
Suspension Platform

Featuring all aluminum railing structure, the XP Series Suspension Platform’s hanging basket is lightweight, easy to operate, and anti-resistant. It is designed with a service life of up to 20 years, which is safe and convenient.

This equipment is convenient, efficient, and stable, with reports and CG certification. It is mainly used in places with high requirements and standards, such as glass curtain walls, bridges, and houses in the construction industry.

Product Details

SafeLock

Overload Detection Device

Electrical Control System

Upper Limit Switch

Hanger

Traction Hoist

Suspension Device Platform

Wall Roller Assembly

SafeLock

Overload Detection Device

Electrical Control System

Upper Limit Switch

Hanger

Traction Hoist

Suspension Device Platform

Wall Roller Assembly

01 / 04

Key Features

  • With all aluminum standard sections of 1, 2, and 3 meters, it is suitable for various sizes.
    The 3S XP series suspension platform has core technologies such as 3S self-developed safety protection system, independent control system, and lifting drive system. It has applied for domestic/international patent protection and obtained CE certification.
  • Limit plate: Set the upper limit, and adjust the height and position.
  • (Customizable) Camera or helmet
    Real-time monitoring of safety hazards on the platform to protect personnel safety.
  • Traction hoist and overload detection device
    Drive the platform to descend and ascend the towers, preventing it from overload operation.
  • Upper limit switch
    Protects the platform from exceeding the safe distance.
  • SafeLock
    Avoid the platform over speed descent.
  • Electrical control system
    Control the operation of the platform, and its alarms sound in case of an emergency.
  • Wall roller assembly
    Telescopic arm can be adjusted to maintain the distance between the platform and the inner wall of the boiler.

SPECIFICATIONS



Model/Series Rated load (Kg) Capacity Self-weight (Kg) Dimensions (m) Rated voltage (V/Hz) Current
(A)
XP-700-2E 280 2 260 2 × 0.7 × 1.065
230V/60
400V50 		15.2
8.8
XP-700-3E 420 4 280 3 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-4E 560 5 310 4 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-5E 700 7 340 5 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-6E 840 9 370 6 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-7E 980 10 400 7 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-8E 970 10 430 8 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-9E 940 10 450 9 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-10E 900 9 480 10 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-11E 860 9 510 11× 0.7 × 1.065 230V/60
400V50 		15.2
8.8
XP-700-12E 820 9 540 12 × 0.7 × 1.065 230V/60
400V50 		15.2
8.8
